Turn on the light at MAX output by pressing the tailcap button until it clicks. Turn on the light at lowest output (programmable) by holding the side switch button while pressing the tailcap button until it clicks. For momentary on function, slightly press the tailcap button To switch between different brightness levels, press the side button switch w/ flashlight on To enter hidden auxiliary mode, press the side switch to cycle through two sets of standard output level to enter
Advanced operations:
Programmable start-up feature: To program the lowest output start-up level to any other level, press the hold the side switch for at least five seconds at other output level to set it as the start-up output level.
Tail strobe feature: Turn the flashlight on and off 20 times (one second or less between each click) to toggle this feature. With the tailcap strobe setting enabled, a double press of the switch button (within one second) will activate the strobe output.
Charging:
Remove the waterproof silicon cap, insert the charging power plug, and turn on the flashlight tailcap switch to charge. Blue side LED indicates the battery is being charged. It reports charging percentage by blinking. When charging is done, remove the charging power plug and turn off the flashlight tailcap switch (wait for a few seconds to let the flashlight circuit to reset itself from charging lock-out status to normal status). When forcing the flashlight to start in high output mode using depleted battery, flashlight will blink to warn user that the battery is unable to keep up the high power input demand. User should switch to lower output and charge the battery as soon as possible.
Output and Runtime
CREE XHP50.2 K2 Cool White LED Led lumen: 25005-1580/1180/430/150/15
Beam Profile
CREE XHP50.2 K2 Cool White LED Center lux: 7,200 lux Beam distance: 185 yards / 170 meters
Battery level report
A blue LED indicator under the main switch reports the estimated battery remaining capacity Flash once: lower than 10% Flash twice: 30%-50% Flash 3x times: 50%-70% Flash 4x times: higher than 70%
Charging level report (charging)
A blue LED indicator under the main switch reports current charging level Flash once: lower than 50% Flash twice: 50%-75% Flash 3 times: >75% Constant on: 100% (done)
DX3B-Clicky Pro flashlight Crenulated stainless steel bezel Harden stainless steel deep pocket two-way clip with titanium alloy dark vacuum coated finish (US only) UL/PSE certified USB 5V 1A wall charger (100V-240V) (EU only) TUV/CE certified USB 5V 1A wall charger (100V-240V) Rigid nylon holster w/ self-retention device 3.7V 18350 1300mAh rechargeable protected li-ion battery (10A discharge) Spare o-rings User Manual Mil-Spec Para-cord Lanyard w/ quick attachment clip Micro USB USB charging cable (3.3feet/1meter) w/ AWG24 copper wire
Other features
LED Copper MCPCB star board with DTP technology and direct heat path User replaceable glass lens Battery reverse polarity protection Ultra low internal resistance phosphor bronze springs (silver coated)
