Beam Profile CREE XM-L2 U2 LED Center lux: 6,300 Center spot angle: 11° Spill light angle: 72° Beam distance: 172 yards / 158 meters
Operations Signal clicky switch Turn on the light at maximum output (constant on) by pressing and holding the on/off switch button Turn on the light at its lowest output (constant on) by pressing and release the switch button within 0.3 second To switch between output levels, (with light turned on) press and hold the on/off switch for longer than 0.6 second to switch to next output. Press and hold the switch will cycle between all levels. To access 1.5Hz blinking mode, (with light turned on) press and hold the on/off switch for more than 10 seconds to enter Button boot voltage indicator (Blue) 1x18650 mode Flashes 3 times (higher than 3.7V) Flashes 2 times (between 3.3V and 3.7V) Flashes once (lower than 3.3V) 2xCR123A mode Flashes 3 times (higher than 4.5V) Flashes 2 times (between 4.5V and 3.5V) Flashes once (lower than 3.5V)
