Created for the professional user community, the M7 utilizes a PMMA lens and its exceptional light transmission capability. Designed using precise spectrum analysis, this light presents a homogeneous beam and creates an even, dark spot free, glare free light zone. Perfectly suited for parts examination and reading or any task requiring close-up illumination. The M7 can be set for two levels of output (High & Low) for its wide illumination area. Compact and light weight, with a length of only 12 cm, the M7 is easy to carry and use anywhere with the included pocket clip. The unibody construction of the M7 gives it a high rate of heat dissipation and shock resistance, complementing the built-in multiple tiers of protection system, including low-voltage warning, reverse polarity protection, and over-discharge protection. "Eye of Heaven General", the Eye of Wisdom, will watch over the hard work you pour your heart into.
Directions:
Open the tail cap by twisting counter-clockwise, insert a charged quality 18650 Li-ion battery with the positive terminal towards the bezel, and tighten the tail cap by turning clockwise.
The flashlight has Reverse Polarity Protection, the light will not be damaged by batteries inserted in the wrong orientation, but it will not turn on. If this occurs, please check the battery orientation.
Fully press the tail switch until "click" is heard to turn on the flashlight. Each time the flashlight is turned on, the default setting is "LOW".
When the flashlight is on, half press the tail switch to cycle between LOW and HIGH output. Fully press the tail switch until "click" is heard to turn off the flashlight.
When the battery voltage is too low, the flashlight will flash 2 times as a warning. When the flash is given, please change to a new battery.
After the first flash warning, the flashlight will operate for several minutes as a safety measure.
After several minutes, the second flash warning will be given. After this warning, the flashlight will shut off automatically.
Aerospace Aluminum Alloy construction; Black anodized finish
Lens: PMMA Lens
Emitter: High efficiency white light X-LED, max output of 176LM/W, lifetime up to 50,000 hours
Output：
Tested with Weltool UB18-35(3500mAh) Rechargeable Li-ion Battery
Low
High
Output
114 Lumens
353 Lumens
Run time
7h40min
1h55min
Candela
117 Candela
365 Candela
Beam Distance
21m
38m
High light transmission PMMA lens
Anti-slip, anti-roll design
Wear resistant threads
Flashlight body features conductive surface
Gold-plated springs
1 meter impact resistance
IP67 water resistance rating
Individually serialized
Dimensions: (Bezel Dia.) 27.5mm x (Body Dia.) 23mm x (Length)119.5mm
